Product Model
726-652
Selling Points
- 1Efficient Module Identification: Mark up to 48 modules with various colors for clear identification.
- 2Robust Design: Built to withstand harsh industrial environments with durable materials.
- 3Versatile Color Options: Choose from gray, white, and dark gray to suit your specific needs.
- 4Global Availability: Distributed worldwide with fast and competitive shipping options.
- 5High-Quality Manufacturing: Manufactured by WAGO, a trusted leader in industrial automation solutions.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 34.6?mm?/ 1.362?inches | Height | 132?mm?/ 5.197?inches |
Depth | 80.7?mm?/ 3.177?inches | Marking | 1 … 24 |
Design | slimline | Note (material data) | Information on material specifications can be found here |
Color | dark gray | Module color | gray |
Material group | I | Insulation material (main housing) | Polyamide (PA66) |
Flammability class per UL94 | V0 | Fire load | 2.129MJ |
Weight | 264.4g | eCl@ss 10.0 | 27-24-26-08 |
eCl@ss 9.0 | 27-24-26-08 | ETIM 9.0 | EC001604 |
ETIM 8.0 | EC001604 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 10?(1)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4055143628624 |
Customs tariff number | 8536904000 | CAS-No. | 7439-92-1 |
REACH Candidate List Substance | Lead | RoHS Compliance Status | Compliant,No Exemption |
SCIP notification number (Austria) | ac368738-aac2-4edd-9c79-417d8e440963 | SCIP notification number (Belgium) | f149c04a-ef18-4506-9c0a-d5463d3514ed |
SCIP notification number (Bulgaria) | 615a923e-3d6a-43d7-b37b-76949e7e1db9 | SCIP notification number (Czech Republic) | 2fb79099-a97d-4a2f-a323-203c34be8b49 |
SCIP notification number (Denmark) | 7858feaf-d0c4-4e39-a494-30761c2a66ec | SCIP notification number (Finland) | 1a15e2bc-e471-4906-a509-2971f1295291 |
SCIP notification number (France) | a084f4f8-3d72-4073-89da-15aa3ca344f3 | SCIP notification number (Germany) | e13c224a-c1ba-4c2c-8271-3569e9d75cdc |
SCIP notification number (Hungary) | a125f98f-6a9b-4256-a5ce-71f9016b9044 | SCIP notification number (Italy) | bd53c018-d0c8-4dbe-8283-bdb216296b49 |
SCIP notification number (Netherlands) | acf61e9e-8d96-4a4e-ac60-4d5a9ebc3048 | SCIP notification number (Poland) | 5636f02e-b9f2-4fac-b079-d13a7bc1a1ae |
SCIP notification number (Romania) | 774ec8ba-99af-49f9-b0ed-b984b5b697e8 | SCIP notification number (Sweden) | 72cee426-2f68-409c-a097-578e4b483c52 |
Rated current | 76A | Rated current 2 | 24A |
Connection type 1 | Page 1 | Connection technology | Push-in CAGE CLAMP? |
Total number of connection points | 2 | Actuation type | Operating tool |
Connectable conductor materials | Copper | Solid conductor | 0.2 … 16?mm2?/ 24 … 6?AWG |
Fine-stranded conductor | 0.2 … 16?mm2?/ 24 … 6?AWG | Strip length | 16 … 17?mm?/ 0.63 … 0.67?inches |
Wiring direction | Front-entry wiring | Connection type 2 | Side 2 |
Connection technology 2 | CAGE CLAMP? | Number of connection points 2 | 2 |
Solid conductor 2 | 0.08 … 2.5?mm2?/ 28 … 14?AWG | Fine-stranded conductor 2 | 0.08 … 2.5?mm2?/ 28 … 14?AWG |
Strip length 2 | 8 … 10?mm?/ 0.31 … 0.39?inches |
Specifications may be subject to change without notice
