Product Model
727-199
Selling Points
- 1Matrix Patching Capability: Designed for feed-through terminal block applications with matrix patching capabilities.
- 2Locking Clips: Features cover locking clips for secure connections.
- 3Test Port: Includes a 2.3 mm Ø test port for easy diagnostics.
- 4DIN-35 Rail Mounting: Suitable for mounting on a DIN-35 rail (35 x 7.5).
- 5Polyamide Material: Made from Polyamide (PA) 66 for durability and reliability.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Note (material data) | Information on material specifications can be found here | Color | dark gray |
Material group | I | Insulation material (main housing) | Polyamide (PA66) |
Flammability class per UL94 | V0 | Fire load | 0.017MJ |
Weight | 0.6g | Processing temperature | -35 … +85?°C |
Continuous operating temperature | -60 … +105?°C | Product Group | 12 (Matrix Patch Board) |
eCl@ss 10.0 | 27-14-11-92 | eCl@ss 9.0 | 27-14-11-92 |
ETIM 9.0 | EC002848 | ETIM 8.0 | EC002848 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 200?(25)?pcs |
Packaging type | box | Country of origin | DE |
GTIN | 4017332577915 | Customs tariff number | 3926909985 |
RoHS Compliance Status | Compliant,No Exemption | Strip length | 8 … 10?mm?/ 0.31 … 0.39?inches |
Specifications may be subject to change without notice
