Product Model
769-208/281-411
Selling Points
- 1Rated at 500 V/32 A for 4 mm² (AWG 12) to ensure safe and reliable connections.
- 2Simple snap-in mounting on perforated metal plates or flat surfaces for quick integration.
- 3Orange end plates provide clear separation and touch-proof safety, preventing electrical shocks.
- 4Compatible with both female plugs and carrier terminal blocks for versatile connection options.
- 5Equipped with locking levers, strain relief plates, and housings for added mechanical protection.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Safety information | A separator plate (Item No. 209-191) or a 10 mm end stop (Item No. 249-117) must be placed at the end of a WAGO X-COM?-SYSTEM terminal strip. | Total number of potentials | 1 |
Number of levels | 1 | Width | 5?mm?/ 0.197?inches |
Height | 87.5?mm?/ 3.445?inches | Depth from upper-edge of DIN-rail | 28.5?mm?/ 1.122?inches |
Design | horizontal type | Mounting type | DIN-35 rail |
Marking level | Center marking | Note (material data) | Information on material specifications can be found here |
Color | gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.17MJ | Weight | 7.7g |
Processing temperature | -35 … +85?°C | Continuous operating temperature | -60 … +105?°C |
Product Group | 18 (X-COM-System) | eCl@ss 10.0 | 27-14-11-27 |
eCl@ss 9.0 | 27-14-11-27 | ETIM 9.0 | EC000903 |
ETIM 8.0 | EC000903 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 50?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4045454198374 |
Customs tariff number | 8536904000 | CAS-No. | 7439-92-1 |
REACH Candidate List Substance | 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol | RoHS Compliance Status | Compliant,With Exemption |
RoHS Exemption | 7(a) | SCIP notification number (Austria) | fc1df530-fdca-434b-93f9-7db8fdbfc0c5 |
SCIP notification number (Belgium) | 2ec01950-d922-4e4a-9d5f-2e4015da988d | SCIP notification number (Bulgaria) | 5cc8e214-2517-493f-9d08-84277fd2ab7b |
SCIP notification number (Czech Republic) | d885d409-7096-4069-9496-0be6067abf8f | SCIP notification number (Denmark) | 1c77f5e2-bfbc-4ef7-962b-2d42c39cd043 |
SCIP notification number (Finland) | 4f8278e0-d908-45ed-9e87-490b077a45cc | SCIP notification number (France) | e5c2b4c0-0f48-4da9-a765-1dde8243f792 |
SCIP notification number (Germany) | a1861d14-a3f5-4241-8934-ec7e722fad44 | SCIP notification number (Hungary) | 6b08d4b7-41b1-48b5-8469-73276155fea2 |
SCIP notification number (Italy) | 0b342d56-1e77-4a33-b5d5-069c46c45e18 | SCIP notification number (Netherlands) | 619eaca3-82d7-4b52-917b-6301b3ef0719 |
SCIP notification number (Poland) | e39de74b-8696-4700-976e-43f5d25897e7 | SCIP notification number (Romania) | ed1f6a6b-9c91-46ec-8225-e74bf9d9a3ce |
SCIP notification number (Sweden) | b2f40034-3e67-4064-b400-7bbb6f805155 | Rated current | 0.5A |
Nominal voltage | 250V | Reverse voltage | 1,000V |
Wiring direction | Front-entry wiring |
Specifications may be subject to change without notice
