Product Model
770-523
Selling Points
- 1High-quality materials ensure long-lasting performance.
- 2Easy to install and configure for quick setup.
- 3Compatible with a wide range of electrical systems.
- 4Durable design withstands harsh environmental conditions.
- 5Ideal for industrial and commercial applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 25.6?mm?/ 1.004?inches | Height | 6.95?mm?/ 0.274?inches |
Depth | 44.8?mm?/ 1.764?inches | Suitable | for socket and plug |
Note (material data) | Information on material specifications can be found here | Color | silver-colored |
Flammability class per UL94 | V0 | Weight | 2.4g |
Material | Copper (SE Cu); special tin coating | Processing temperature | -5 … +40?°C |
Continuous operating temperature | -35 … +85?°C | Note on continuous operating temperature | Insulating parts for temperatures ≤ 105 °C |
Product Group | 20 (Winsta) | eCl@ss 10.0 | 27-44-06-92 |
eCl@ss 9.0 | 27-44-06-92 | ETIM 9.0 | EC002863 |
ETIM 8.0 | EC002863 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 50?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4045454662684 |
Customs tariff number | 7409909060 | RoHS Compliance Status | Compliant,No Exemption |
Number of poles | 3 |
Specifications may be subject to change without notice
