Product Model
789-112
Selling Points
- 1Fast and vibration-proof connections with spring pressure technology.
- 2Suitable for solid, stranded, and fine-stranded conductors with ferrules.
- 3Silver-colored, unplated design for reliable electrical connections.
- 4Industry-proven design for maintenance-free operation.
- 5Compact dimensions: 0.9 mm depth, 13.5 mm height, and 7.716 inches width.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Rated current | 16A | Width | 196?mm?/ 7.716?inches |
Height | 13.5?mm?/ 0.531?inches | Depth | 0.9?mm?/ 0.035?inches |
Color | silver-colored | Weight | 4.3g |
eCl@ss 10.0 | 27-14-11-40 | eCl@ss 9.0 | 27-14-11-40 |
ETIM 9.0 | EC002586 | ETIM 8.0 | EC002586 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 5?pcs |
Packaging type | bag | Country of origin | DE |
GTIN | 4055143926041 | Customs tariff number | 8536698000 |
RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
