Product Model
811-477
Selling Points
- 1DIN-Rail Mounting: Mounts securely on DIN-35 rail for easy installation.
- 2CAGE CLAMP Connection: Securely connects conductors up to 16 mm² with CAGE CLAMP technology.
- 3High Safety Standards: Meets IEC/HD 60269-2 overvoltage category for enhanced safety.
- 4Versatile Conductor Termination: Supports solid and fine-stranded conductors, including copper and AWG sizes.
- 5Compact Design: Measures 35 mm wide, 105 mm high, and 55 mm deep from the upper edge of the DIN-rail.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Note (material data) | Information on material specifications can be found here | Color | light gray |
Weight | 30g | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-40 | ETIM 9.0 | EC000489 |
ETIM 8.0 | EC000489 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 20?(10)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4050821838593 |
Customs tariff number | 8536698000 | RoHS Compliance Status | Compliant,No Exemption |
Rated voltage (III / 3) | 1000V | Rated current | 63A |
Specifications may be subject to change without notice
