Product Model
859-357
Selling Points
- 1Industrial-grade reliability: Designed for demanding industrial environments.
- 2Versatile applications: Suitable for manufacturing and process control systems.
- 3High-performance contacts: 1C/O / SPDT contact configuration ensures precise control.
- 4Compact design: DIN-35 mounting makes it easy to integrate into existing systems.
- 5Durable construction: Electromechanical design with CAGE CLAMP connections for secure connections.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Note | To protect the relay coils and contacts, inductive loads must be dampened with an effective protection circuit. | Rated voltage | 300V |
Rated surge voltage | 4kV | Overvoltage category | III |
Pollution degree | 2 | Dielectric strength (control/load circuit) (AC, 1?min) | 4?kVrms |
Dielectric strength (open contact) (AC, 1?min) | 1?kVrms | Insulation type (control/load circuit) | Reinforced insulation (safe isolation) |
Insulation type (adjacent devices) | Reinforced insulation (safe isolation) | Protection type | IP20; in connected state or when using 859-525 end plate |
Connection technology | CAGE CLAMP? | Solid conductor | 0.08 … 2.5?mm2?/ 28 … 14?AWG |
Fine-stranded conductor | 0.08 … 2.5?mm2?/ 28 … 14?AWG | Fine-stranded conductor; with insulated ferrule | 0.08 … 1.5?mm2?/ 28 … 16?AWG |
Strip length | 5 … 6?mm?/ 0.2 … 0.24?inches | Width | 6?mm?/ 0.236?inches |
Height | 91?mm?/ 3.583?inches | Depth from upper-edge of DIN-rail | 56?mm?/ 2.205?inches |
Mounting type | DIN-35 rail | Mounting position | Horizontal (standing/lying); vertical |
Note (material data) | Information on material specifications can be found here | Color | gray |
Insulation material (main housing) | Polyamide (PA66) | Material group | I |
Flammability class per UL94 | V0 | Fire load | 0.338MJ |
Weight | 22.6g | Ambient temperature (operation at U<sub>N</sub>) | -40 … +50 °C |
Ambient temperature (storage) | -40 … +70 °C | Processing temperature | -25 … +50?°C |
Temperature range of connection cable | ≥ (Tambient+ 20 K) | Relative humidity | 5 … 95?% (no condensation permissible) |
Operating altitude (max.) | 2000m | Standards/specifications | EN 61010-2-201 |
Product Group | 6 (INTERFACE ELECTRONIC) | eCl@ss 10.0 | 27-37-16-01 |
eCl@ss 9.0 | 27-37-16-01 | ETIM 9.0 | EC001437 |
ETIM 8.0 | EC001437 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 10?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4055143604147 |
Customs tariff number | 8536490050 | CAS-No. | 7439-92-1 |
REACH Candidate List Substance | 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol | RoHS Compliance Status | Compliant,With Exemption |
RoHS Exemption | 7(a) | SCIP notification number (Austria) | 18218543-377f-4193-87a4-47ee52cf4d62 |
SCIP notification number (Belgium) | 8f2f547f-3699-4dfa-a1e3-08fee567de86 | SCIP notification number (Bulgaria) | ab3db4d4-d568-47a9-b222-c036ae67bca5 |
SCIP notification number (Czech Republic) | e54048af-1b04-46f5-a3b0-e27dddab0511 | SCIP notification number (Denmark) | e1ed483d-317d-4871-b460-20b3b31b8a85 |
SCIP notification number (Finland) | fd3eb2d6-76df-4c50-93d5-cf766dda1501 | SCIP notification number (France) | 820ae024-0648-42bc-8e7c-7f14c8682944 |
SCIP notification number (Germany) | 1bab649a-fe75-4b0f-a564-14d69e10e888 | SCIP notification number (Hungary) | 423d0e38-72cf-4aec-8100-2e7ec42fde33 |
SCIP notification number (Italy) | 4770c590-50f3-469c-9ce2-65d033bab62b | SCIP notification number (Netherlands) | 53a09c75-5198-4b3d-896e-9820e9ff2b65 |
SCIP notification number (Poland) | 89d7c1f9-86f5-4a69-b1a1-1f2e97c1cc4d | SCIP notification number (Romania) | 922f9e28-b8cb-41fa-89c7-57e3be014ecd |
SCIP notification number (Sweden) | 202c1e45-a6e5-4614-b2c1-86416f10f951 | Nominal input voltage U<sub>N</sub> | AC/DC?115?V |
Input voltage range | -15 … +10?% | Nominal input current at U<sub>N</sub> | 4?mA |
Number of changeover contacts | 1 | Contact material (relay) | AgSnO2 |
Limiting continuous current | 5?A | Inrush current (resistive) max. | (AC) 20?A?/ 0.02?s |
Switching Voltage, Max. | AC?250?V | Switching power (resistive) max. | AC?1250?VA;?DC (see load limit curve) |
Switching capacity | AC-15:?3?A?/ AC?250?V;?DC-13:?2?A?/ DC?24?V | Recommended minimum load | 10?V?/ 10?mA;?24?V?/ 1?mA |
Pull-in time (typ.) | 15ms | Drop-out time (typ.) | 25ms |
Bounce time (typ.) | 3.5ms | Electrical life (NO; resistive load; 23?°C) | 50?x 103 switching operations |
Mechanical life | 5?x 10? switching operations | Switching frequency with/without load (max.) | 6?min-1/ 180?min-1 |
Status indicator | Red LED |
Specifications may be subject to change without notice
