Product Model
859-409
Selling Points
- 1Designed for easy installation on DIN rails.
- 2Handles up to 18A, ensuring reliable connections.
- 3Visual confirmation of connection status with LED lights.
- 4Simplifies troubleshooting with integrated test ports.
- 5Customizable marking options for easy identification and organization.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Rated current | 18A | Width | 52?mm?/ 2.047?inches |
Height | 21.5?mm?/ 0.846?inches | Depth | 2.5?mm?/ 0.098?inches |
Color | light gray | Fire load | 0.048MJ |
Weight | 5g | Product Group | 6 (INTERFACE ELECTRONIC) |
eCl@ss 10.0 | 27-14-11-40 | eCl@ss 9.0 | 27-14-11-40 |
ETIM 9.0 | EC002586 | ETIM 8.0 | EC002586 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 25?(25)?pcs |
Packaging type | box | Country of origin | DE |
GTIN | 4066966274028 | Customs tariff number | 8536698000 |
RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
