Product Model
870-405
Selling Points
- 1High-quality copper contacts ensure reliable connections.
- 2Compact design fits in tight spaces, ideal for industrial applications.
- 3Easy-to-use screw-clamp termination simplifies wiring.
- 4Durable construction withstands harsh environmental conditions.
- 5Compatible with a wide range of wire sizes and types.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 24?mm?/ 0.945?inches | Height | 2.5?mm?/ 0.098?inches |
Jumper assignment | 1-2-3-4-5 | Note (material data) | Information on material specifications can be found here |
Color | light gray | Fire load | 0.021MJ |
Weight | 2.2g | Product Group | 16 (Rail Mounted Terminal Blocks with CCC) |
eCl@ss 10.0 | 27-14-11-40 | eCl@ss 9.0 | 27-14-11-40 |
ETIM 9.0 | EC000489 | ETIM 8.0 | EC000489 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 25?(25)?pcs |
Packaging type | Bag | Country of origin | DE |
GTIN | 4066966271737 | Customs tariff number | 8536698000 |
RoHS Compliance Status | Compliant,No Exemption | Rated current | 18A |
Rated current (Ex e II) | 13.5A |
Specifications may be subject to change without notice
